Specification

1. X-ray generator

- Power voltage: Single - phase 3 wires 220V+22V

- Frequency: 50Hz+1Hz

- Input power: 20kW

- Tube current: 32mA~200mA

- Tube voltage: 40kV~120kV

- mAs: 0.32mAs~2000mAs

- Exposure time: 0.01s~4s

2. X-ray Tube

- Max Tube voltage: 125kV

- Focus: Small focus: 1.0mm; big focus: 2.0mm

- Anode input power: small focus 21kW ; big focus 42.5kW

- Rotation Speed of anode: 2700rpm

- Thermal capacity of Anode: 140kHU

3. Collimator

- Control method of Lead-door: Manual

4. Radiography Bed

- Size: 2000x650x690mm

5. Grid (18" x18")

- Size: 18" x18"

- Grid Ratio: 10:1

- Grid Density: 40L/cm

6. Flat Panel Detector

- Material: Amorphous dilicon crystal

- Size of Acquisition: 43x43cm (17x17 inch)

- Pixel Size <= 127Mm

- A/D Conversion: 16Bit

- Pixel Matrix: 3328x3328 (11 Million Pixels)

- Preview time <=2s

7. Workstation

- CPU: >=2.8GHz

- Memories: 2GB

- Hard Disk: 500GB

- Monitor: 19" LCD Monitor

- Image Acquisition, Image enlargement and reduction, Image brightness adijustment, Image contrast adjustment, Image Orientation, Image rollover

- 100M internet interface; Can transfer, Query, Edit and print the image by Dicom3.0

- Management the information of the patient
